SZY-G2L: Vacuum Filter
SZY-G2L: Vacuum Filter
Couldn't load pickup availability
Share
Product Information
The vacuum filter SZY-G2L is easy to install, portable, and can be used with plastic vacuum devices. It is suitable for scenarios that require small amounts of air extraction at a slow speed. This product can be used for vacuum filtration, solvent filtration, vacuum distillation, vacuuming closed containers, air circulation, air extraction, etc., in laboratory settings. The instrument is compact in size, making it convenient for storage and transportation.
Product Features
1.Can replace filter membranes of different apertures according to usage requirements.
2.The filtration device with installed microporous filter membrane can undergo high-temperature and high-pressure sterilization as a whole.
3.Simple installation, flexible replacement, knob speed adjustment, quick operation.
4.Compact size, lightweight, easy to carry.
5.Ultra-long battery life.
Product Parameters
Rated Voltage
| Product Name | Vaccum Filter |
| Battery Level Display | LED display |
| Motor Type | Micro Diaphragm Vacuum Pump |
| Air Aspiration Speed | ≥5 L/min |
| Filtration Method | Microporous Filter Membrane |
| Control Method | Knob Switch |
| Weight | 0.84 kg |
| Battery Capacity | 2600 mA |
| Noise Level | ≤60 dB |
| Air Filtration | 0.45 µm Hydrophobic Filter Membrane |
| Power | 6 W |
| Rated Voltage | AC100-240 V ，50/60 Hz |
| Power supply spec. |
24 V，1 A |
| Maximum Vacuum Degree | ≤-60 Kpa(-450 mmHg) |
| Speed regulation mode | Knob speed regulation |
| Allowable ambient humidity | 5-40 ℃ 80% RH |
| Dimensions | 185×155×390 mm |
| Volume of Flask | 2 L |
Product Information
The vacuum filter SZY-G2L is easy to install, portable, and can be used with plastic vacuum devices. It is suitable for scenarios that require small amounts of air extraction at a slow speed. This product can be used for vacuum filtration, solvent filtration, vacuum distillation, vacuuming closed containers, air circulation, air extraction, etc., in laboratory settings. The instrument is compact in size, making it convenient for storage and transportation.
Product Features
1.Can replace filter membranes of different apertures according to usage requirements.
2.The filtration device with installed microporous filter membrane can undergo high-temperature and high-pressure sterilization as a whole.
3.Simple installation, flexible replacement, knob speed adjustment, quick operation.
4.Compact size, lightweight, easy to carry.
5.Ultra-long battery life.
Product Parameters
Rated Voltage
| Product Name | Vaccum Filter |
| Battery Level Display | LED display |
| Motor Type | Micro Diaphragm Vacuum Pump |
| Air Aspiration Speed | ≥5 L/min |
| Filtration Method | Microporous Filter Membrane |
| Control Method | Knob Switch |
| Weight | 0.84 kg |
| Battery Capacity | 2600 mA |
| Noise Level | ≤60 dB |
| Air Filtration | 0.45 µm Hydrophobic Filter Membrane |
| Power | 6 W |
| Rated Voltage | AC100-240 V ，50/60 Hz |
| Power supply spec. |
24 V，1 A |
| Maximum Vacuum Degree | ≤-60 Kpa(-450 mmHg) |
| Speed regulation mode | Knob speed regulation |
| Allowable ambient humidity | 5-40 ℃ 80% RH |
| Dimensions | 185×155×390 mm |
| Volume of Flask | 2 L |
